midas MeshFree 2026 Introduction

Core Technology: The Implicit Boundary Method (IBM)

Key Benefits and Capabilities

• Elimination of Meshing: The software completely frees engineers from the difficulties of traditional meshing and CAD cleanup. By bypassing these steps, designers can validate design concepts in real-time and achieve results significantly faster.
• High Accuracy: Despite bypassing traditional meshing, midas MeshFree is highly reliable, demonstrating 96% or higher tested accuracy when compared to existing traditional FEM results.
• Seamless CAD Integration: The 2026 R1 release includes updates to CAD interaction, ensuring smoother data exchange and model handling.

Enhancements in the 2026 Release

Summary

Free Download Midas MeshFree for Windows PC is a design and analysis of cutting-edge technology developed as a joint project with Samsung Electronics. MeshFree performs finite element analysis on the original CAD model without meshing or defeaturing. MeshFree frees you from all the difficulties of today’s design and analysis software.

Overview of Midas MeshFree Benefits

Midas MeshFree is reliable and efficient, bringing you a 96% or higher tested accuracy in agreement with existing FEM results. Midas MeshFree provides the powerful analysis tools and optimal design techniques required for efficient work during the design phase.

midasNFX is an integrated finite element analysis program for structural, CFD simulation, and optimization design. It provides efficient and accurate analysis and an integrated pre-post processor developed by senior mechanical engineers with over 20 years of CAE software development expertise.

Midas NFX provides total solutions from high-end structural analysis functions such as contact analysis, nonlinear analysis, implicit/explicit dynamic analysis, and fatigue analysis, in addition to high-end fluid analysis functions such as moving mesh, free surface analysis, and mass transfer analysis. Additionally, midas NFX provides practical topology and size optimization considering static/dynamic analyses and manufacturing processes.

Overview of Midas MeshFree Features

• The Static Linear
• Modal
• Heat Transfer
• Thermal Stress
• PreStress
• Topology Optimization
• Transient Response
• Frequency Response
• Random Response
• Response Spectrum
• Nonlinear the Static
• Transient Heat Transfer

Technical Details and System Requirements

• Supported OS: Windows 11 / Windows 10 / Windows 8.1 / Windows 7
• Processor: Multicore Intel Series or above, Xeon or AMD equivalent
• RAM: 4GB (8GB or more recommended)
• Free Hard Disk Space: 4GB or more recommended

MeshFree

midas MeshFree is a cutting-edge design and analysis technology developed through the collaboration with SAMSUNG Electronics. It performs simulation of the original model you have designed without any modification. Conventional FEM required tedious and time consuming model idealization and cleanup process. However, MeshFree has the latest, efficient and effective numerical analysis algorithm that can simulate using the original 3D CAD model itself.midas MeshFree performs analysis based on Implicit Boundary Method. General meshless method calculates deformation at the position of nodes only. Accuracy of the analysis result depends on the density of nodes. Also additional calculation of stress is required after creating internal elements. Therefore it requires large amount of memory and calculation time.However midas MeshFree solves a problem with the identical method as FEA using 20 nodes-Hexa element structural grid. In addition it calculates results in boundary surfaces with the special integralformula. Therefore it is possible to analyze a problem faster with low usage of memory.
